PQA: Power Quality Analyzing & Reporting (ADK: D-5/919) – Presentation PDF on 50 + pages Assuring of the quality of the voltage, current and phase angle recording over standardised period of time according to IEEE 1448, IEEE 1459, IEEE 519, IEC 61000 series, EN 50160 and several other with reporting accordingly.
PQA – Presentation PDF: Power Quality Analyzing & Reporting
10,50 €
Description
Practical Knowledge with Measuring Methods and Procedures
Inspections, Tests & Measurements
- Automatic Voltage and Power Quality Analysis according to EN 50160 with PASS / FAIL limit evaluation, including flickers and harmonics;
- IEEE-519 Recommended Practice and Requirements for Harmonics Control in Electric Power Systems report creation;
- Energy Demand report creation;
- Power quality standard IEC 61000-4-30 Class A. Predefined recorder profile for EN 50160 survey;
- Use of Troubleshooting and Maintenance Tool to discover voltage sags and swells, resonant states, high neutral conductor currents in 3-phase systems, asymmetry, transients;
- Compare the results simultaneously for evaluate operating of filtering systems, power correction equipment, over voltage protection and UPS systems;
- Use of Power Quality Negotiating Tool;
Evaluation of Results
- Find the PASS / FAIL / LIMIT values
- Compare results to the limit
- Bring the decision
Act and Inform Appropriately
- Report the results
- Mark the equipment accordingly
- Enabling of further use when PASS
- Rejecting the usage when FAIL
- Inform and transfer the responsibility
Troubleshooting and Maintenance
- Work close to energised objects
- Hi Voltage presence Checking
- Tracing of transients
- Harmonics and THD, Filters evaluation
- Currents, Voltages and Phase angle
